2.5KWH Movable Energy Storage Power System 2500wh LiFePO4 Battery Pack

This Movable energy storage power 2.5KWH system is a pioneering portable energy storage solution that features safety, flexibility, and stylish design at the same time. It has 3 operating modes (matching load, standby power mode, peak shaving and valley filling), which can meet various power demands of users and ensure safe and reliable power supply for various applications. The unique handle design makes it easy for you to carry it to more places.

Share:

  • facebook
  • twitter
  • linkedin
  • pinterest
  • Ins

Protection:

  • On-time Dispatch Guarantee
  • Support 24/7
Product details
Company profile

Overview

Parameter Details

  • Nominal Voltage:12V
  • Nominal Capacity:200AH
  • Nominal Energy:2500WH
  • Battery Type:LiFePO4
  • Net Weight:28kg
  • Product Size:260x200x300mm
  • Battery Certification:UN38.3,MSDS,UL
  • Environmental Certification:Rohs,REACH

Product Pictures



Energy Storage System LiFePO4 Battery Pack Movable energy storage 2500WH

More Parameters



Name Specifications Parameter Quantity Remarks
Battery 2500WH Lithium iron phosphate battery pack 1
Input port 12V input Maximum 10A 120W 1 Maximum input power 500W
Solar charging input Maximum open circuit voltage 100V
MPPT:25V-50V
Mains power input 110V,11.4A;220V,5.68A,Maximum 1250W 1 4 ports on the back: A, B, C, D any port
Output port USB-A output 5V,2.1A,Maximum 10.5W 2 Top 2, slow charging
11V, 3A or 9V, 2A or 5V, 4A, maximum 33W 2 Next 2, PD fast charging
12V output 12V,10A,Maximum 120W 1
TYPE-C output 20V, 3.25A or 15V, 3A or 9V, 3A or 5V, 4A, 65W maximum 2 PD fast charging
AC output 110V edition:Single port maximum110v 22.72A 1 Total rated power 2500W, maximum 5000W (3 seconds duration)
220V edition:Single port maximum 220v  11.36A 1
Size product:260X200X300MM Wooden box:420X280X310MM
Shell material Top ABS plastic,PC plastic
Side 201 stainless steel plate
handle Aluminium alloy
Net weight 28kg 32kg Estimated weight
Heat dissipation mode Cooling fan 4
Gross weight 33.5kg Estimated weight
Executive standards GB/T 36558-2018《General Technical Conditions for Electrochemical Energy Storage System of Power System》
Battery certification UN38.3,MSDS,UL
Complete machine certification Meet CE,FCC,ETL
Environmental certification Rohs,REACH
